5 Ton Cabinet R-32 Compatible 10-Year Parts Warranty 208/230V Single-Phase

Indoor air handler for Everwell matched split systems. Includes a built-in R-32 evaporator coil. Multi-position installation — works in upflow, downflow, or horizontal orientation.

Key Features

This Everwell multi-position air handler is designed for 5.0 ton R-454B refrigerant systems and supports upflow, downflow, or horizontal installation. It pairs with compatible cooling-only or heat pump condensing units and includes a built-in A2L refrigerant leak sensor for added safety. AHRI Certified and ETL Listed.

A2L refrigerant sensor — built-in leak detection automatically shuts down the system and runs the fan at high speed to clear vents if a leak is detected.
Flexible installation — supports upflow, downflow, or horizontal configurations to fit closet, attic, or basement applications.
All-copper coils — for long-term durability and efficient heat transfer.
Compatible with cooling-only and heat pump systems — when paired with a matching condensing unit.
Multi-speed ECM motor — (select models) — variable-speed blower for improved comfort and energy efficiency.
Insulated, powder-coated galvanized steel cabinet — for corrosion resistance and quiet operation.
Built-in filter rack — for easy maintenance.
Optional electric heat kit compatibility — from 5–20 kW for supplemental heating.

What This Is

This is the indoor half of an Everwell matched split system — the unit that moves conditioned air through the ductwork. It contains the blower motor and the evaporator coil where refrigerant from the outdoor condenser absorbs heat from your indoor air.

This air handler accepts a field-installable electric heat kit for backup heating in heat pump systems or as primary heating in air conditioner systems with electric heat.

Specifications

Cabinet & Capacity
Tonnage Range	5 Ton
Refrigerant	R-32 (evaporator coil pre-installed)
Installation Position	Multi-Position (upflow / downflow / horizontal)
Blower Motor	ECM Multi-Speed
Electrical
Voltage	208/230V, Single Phase, 60Hz
Heat Kit Compatibility	Field-installable (Everwell WTM series)

Dimensions

Cabinet dimensions for AHC6014BA15

22"

Width

24 1/2"

Depth

53 1/8"

Height

Warranty

Backed by Everwell's standard manufacturer warranty

Year Limited Coil

Year Parts (Registered)

Year Compressor (Registered)

Warranty terms require online product registration within 60 days of installation. See official Everwell warranty documents for complete terms and conditions.

Documentation

Manufacturer spec sheets for this product

CAC/AHC/FAHC 15-Series Technical Sheet
PDF — Tap to download

Common Questions

What size condenser does this pair with?

This is a 5-Ton cabinet. It's designed to pair with Everwell CAC-series condensers in the same tonnage range. The 2-Ton cabinet (AHC2414) typically pairs with 1.5–2.0 Ton condensers.

Do I need a separate evaporator coil?

No. The evaporator coil is pre-installed inside the air handler cabinet — already charged with R-32 and ready to connect to your outdoor unit's line set.

Can this be used with a heat pump?

Yes. This air handler works with both AC condensers (for cooling-only systems) and heat pump condensers (for systems that heat and cool). For colder climates, add an electric heat kit for backup heat on the coldest days.

What about an electric heat kit?

Heat kits are sold separately (Everwell WTM series, 5kW–15kW options). They install in the field and provide supplemental electric heat. Required for AC + electric heat configurations; recommended for heat pump systems in cold climates.
